370 LED Bulkhead Light

The C370 Surface Mounted Single Lighting Rectangular Light is an innovative and versatile LED luminaire designed for all-day lighting needs. This maintenance-free, low-energy fixture combines high-power LED lamps with an optimized die-cast aluminum housing and diffuser design to deliver exceptional lighting quality and reliability. Suitable for a wide range of applications, the C370 offers intelligent brightness adjustment for a more efficient, reliable, and durable lighting solution.

Technical Specifications

Model	C370Y220L10-5	C370Y220L20-3
Input Voltage	220-240VAC
Power	10W	20W
Light Source	LED
Luminous Flux	>1000lm	>1800lm
Temperature	4000K/6000K
Dimming Function	7 steps (40%,60%,70%,80%,90%,100%)
Charging Time	24 Hours
Emergency Duration	2 Hours
Emergency Brightness	500lm
Battery	Ni-MH/Ni-CD 6V/2500mAh
Life Span	>50000H
Housing Material	Powder-painted die-cast aluminum
Lampshade Material	Flame retardant V0 PC
IP rating	IP54
Surge Immunity Level	4KV
Net Weight	1.92 Kg

Product Details

Product Specifications

The C370 comes in two models: C370Z220L10 with a power of 10W and C370Z220L20 with a power of 20W. Both models operate on an input voltage of 220-240VAC and feature a 4000K LED light source. The luminous flux for the 10W model is over 1000lm, while the 20W model boasts a luminous flux of over 1800lm. With a temperature rating of 4000K, this light provides a neutral white light that is perfect for various settings.

Features

The C370 is equipped with a 7-step dimming function, allowing users to adjust the brightness to 40%, 60%, 70%, 80%, 90%, or 100% to suit their needs. This feature not only enhances user experience but also helps in conserving energy. Additionally, the light has a lifespan of over 50,000 hours, ensuring long-lasting performance.

Advantages

The C370's optimized die-cast aluminum housing and flame retardant V0 PC lampshade provide excellent heat dissipation and durability. The IP54 rating ensures that the light is protected against dust and splashing water, making it suitable for indoor and outdoor applications. Furthermore, the surge immunity level of 4KV guarantees protection against electrical surges.

User Experience

The C370's intelligent brightness adjustment feature allows users to create the perfect lighting environment for any occasion. The easy-to-use dimming function provides flexibility in lighting control, enhancing the overall user experience. The light's neutral white color temperature also contributes to a pleasant and comfortable lighting atmosphere.

Material

The C370's housing is made of powder-painted die-cast aluminum, which is durable and corrosion-resistant. The lampshade is made of flame retardant V0 PC, ensuring safety and compliance with fire regulations. These high-quality materials contribute to the light's long-lasting performance and reliability.

Installation

Installing the C370 is quick and easy. The surface-mounted design allows for simple installation on walls or ceilings, making it a versatile lighting solution for various applications. The light's compact size and sleek design also make it an excellent choice for modern and contemporary spaces.

Applications

The C370 is perfect for a wide range of applications, including public corridors, staircases, industrial areas, and underpasses. Its versatile design and intelligent brightness adjustment make it an ideal choice for both commercial and residential settings.

Sustainability

The C370 is designed with sustainability in mind. The use of energy-efficient LED lamps and intelligent brightness adjustment helps in reducing energy consumption and carbon emissions. The light's long lifespan also reduces the need for frequent replacements, further contributing to its environmental benefits.

Customization, OEM, and ODM Services

We offer customization, OEM, and ODM services to meet the unique needs of our clients. Whether you need a specific color temperature, dimming range, or housing material, we can tailor the C370 to suit your requirements. Our team of experts will work closely with you to ensure that the final product meets your expectations and specifications.

Various Certifications

The C370 can be certified to meet various international standards and regulations, depending on your needs. Our team will work with you to determine the appropriate certifications and ensure that the light complies with all relevant requirements. This ensures that the C370 is safe, reliable, and suitable for use in various countries and regions.
